What is stereo?




There are now two system of high fidelity, monophonic (monaural) and stereophonic. Monophonic is a system that starts from one microphone and is fed through a single high fidelity set. Stereophonic is a double system. Two separate microphones are placed at different sides of the orchestra and two different systems are used to keep the two signals or channels separated. Two separate speakers are used, placed on different sides of you room. Stereo is much like 3-D photography, two slightly different sound reach your ears giving you a new dimension in sound.



H.H. Scott '59





B&W DM-330

DM330
Stand-mount/Bookshelf loudspeaker system
Product Summary
- An irresistible combination of super sensitivity, high acoustical output – at low cost.
- Bouquets from hi-fi critics for the DM110/DM220 included this from Geoffrey Horn of Gramophone “so I say to B&W how do you follow that?” with the DM330 – that’s how Mr Horn!. Technical highlights
- Refinements in the enclosure give the DM series reduced in lower mid-band coloration and a dramatic improvement in transient response.
- Advanced optimisation techniques employing modal analyses of the cabinet structure were a design feature of the enclosure in all four monitors.

Drive Units:
1 x 26 mm dome/coil construction of special polymide material
2 x 200 mm nominal piston dia and
26 mm high temperature voice coil with critically impregnated composite short fibre cone
Frequency Response: ± 3dB 48 Hz to 20 kHz
Sensitivity: 91 dB (2.83V, 1m)
Power Handling: 10W – 100W
Dimensions: Height: 857 mm, Width: 290 mm, Depth: 320 mm
Finish: American Walnut or Black Ash vinyl
