Musical Fidelity FCD

Features and benefits

Remote control - convenient operation from listening position, including output level.

Bitstream converter system - increased sound quality with smoother response and lower distortion.

20-bit digital filter - high linearity and low distortion

Gold plated phono sockets - do not tarnish and will maintain good contact.

20 track programming - you can listen to the tracks you want in the order you prefer.

Optical and coaxial digital outputs - enables connection of external D/A converters or digital amplifiers.

Class A valve triode output stage - adds the inherent benefits of Class A and valves to the digital format.

XLR output option - makes a better electrical connection than standard phono connectors

Specification

Frequency response: 1 Hz - 20 kHz ±1dB

S/N ratio: > -90 dB (1kHz)

Dynamic range: > -98 dB (1 kHz)

Harmonic distortion: <0.05% (1 kHz)

Wow and flutter: Not measurable (quartz accuracy)

Channel separation: >102 dB (1 kHz)

Output analog: 1.65 V rms

Output digital: 0.5 Vp-p/75 ohm (coaxial)

D/A converter: Bitstream conversion

Digital filter: 8-times oversampling, 20-bit digital filter

Analog filter: 3rd order Butterworth filter

Analog output: Valve Class A triode

Pick-up type: 2D parallel objective lens drive, 3 beam GaA1As semiconductor laser

Wavelenght: 780 mm

Power consumption: 20 watts

Dimensions (W x H x D): 482 x 118 x 330 mm (height includes feet)

Weight: 8,5 kg

Remote control: 1 unit
