Revox B 710 (1981)

Revox B710 Tape Recorder

4-engine drive assembly Revox dedicates special care to the substantial functions of the cassette device. 2-directly propelling quartz-synchronized capstan engines guarantee accurate synchronisation and tape feed without jerking.

The cassette tape recorder Revox B710 sets new standards. Original-faithful admission and refined mixing technology inspire even the professional. For the reliability and longevity the name vouches Revox. Owing to its technical superiority the Revox B710 is incomparable and expels their owner as a connoisseur. Revox B710 fulfills its high requirement in terms of musical truth compromiseless.

HIGH CONVENIENT OPERATION REVOX B710 arranged the controls clear and clearly. Left the push buttons controlling of the drive assembly, the digital display for speedometer and clock as well as switch for Dolby B and Dolby C are attached. Right are stereo input levels adjustments, LED controlling chain, microphone entrances and phones-output. Behind the Revox screen the keys for tape typ choice, timer enterprise as well as starting and stopping inch input line. This convenient operation gives the necessary clearance to the HiFi lover to leave to its formative conceptions free run. The Revox B710 is just as long-lived as all components of the high-quality Revox program. Their conception corresponds already today to the requirements from tomorrow.

Two precision engines provide for fast rewinding and grant a highest possible measure of volume indulgence. No other equipment seizes your cartridges so gently and surely to a life long. The assembly of the four engines on a twisting-free pressure pouring chassis, on whatever the three separated Sendust and ferrite Revox B710 clay/tone heads are attached, secures the stability of the drive assembly.

DOLBY B AND DOLBY C INTERCARRIER NOISE SUPPRESSOR REVOX uses the Dolby system and knows therefore no disturbing volume noise. Additionally to the Dolby B the B710 MK II is equipped with Dolby C. Revox B710 system represents the optimal solution for the intercarrier noise suppressor within the problematic elevator range.

SPECIFICATIONS

Transport mechanism:

4-motor dual capstan drive for Compact Cassettes;

2 DC-spooling motors controlled by microprocessor;

2 capstan shafts individually driven by quartz controlled MDD motors.

7-segment display: 4 digit tape counter switchable to time clock

Useable cassettes: C46 to C120

Tape speed: 4,76 cm/s (17/8 ips)

Wow anf flutter: 0,1% with C60 and C90 cassettes

Winding times: approx 45 sec for C60; 65 sec for C90

Noise reduction systems: Dolby B, Dolby C processors in the recording reproducing channels, switchable MPX filter

Tape selection:

IEC I - Fe₂O₃;

IEC II - CrO₂;

IEC IV - Metal;

AUTO - automatic sensing of coded cassettes

Playback equalization:

3180 + 120μs IEC I;

3180 + 70μs IEC iII + IV

Recording level: 200 nWb/m equals 0 dB on peak level meters

Distortion (at 315 Hz, 0dB):

IEC I: better than 0,8%;

IEC II: better than 1,5%;

IEC IV: better than 1,5%

Frequency response (measured via tape at -20 dB):

IEC I: 30 - 18,000 Hz +2/-3 dB;

IEC II and IV: 30 - 20,000 Hz +2/-3 dB;

Signal to noise ratio: better than 72 dB

Separation (at 1 kHz): better than 40 dB

Bias and erase frequency: 105 kHz

Inputs per channel (sensitivity for 0 dB):

MIC: 0,35 mV/10 kohms (unbalanced);

LINE: 35 mV/220 kohms

Overload margin on all inputs: 40 dB (1:100)

Outputs per channel (level at 0 dB reading):

Line output: max. 0,775 V Ri 390 ohms, max. 1,5 kohms adjustable to -26 dB;

Phones: max. 2,45 V optimal headphone impedance 200 ... 600 ohms, short-circuit-proof. volume separatly adjustable

Component parts: 1 microprocessor 2 kx 8 bit, 55 IC, 86 transistors, 57 diodes, 10 LED, 3 fullwave rectifiers, 2 relays, 4 seven-segment display, 2 24-segment bar graphs, 2 quartz

Voltage selector: 100/120/140/200/220/240 V AC ±10%, 50/60 Hz, max. 50 W

Fuse: 100 ...140 V: 500 mA; 200 ... 240 V: 250 mA

Dimensions (W x H x D): 452 x 151 x 352 mm (17,8 x 6 x 13,85 inches)

Weight: 10,4 kg (22 lbs 15 oz)
